TAPERCONNECTION

Tip size D

Head tipe

FlushingHolesNumbers

Diameter(mm) x Tapered(0)

d x a

Brt No.

INCH

Front

Side

1-1/8

A1

1

1

22X120

S5B28T1222

1-3/16

A2

1

2

22X60

S4B30T622

A4

1

1

22X70

S7B30T722

1-1/4

A2

1

2

22X60

S4B32T622

A3

1

2

22X60

S5B32T622

A2

1

2

22X70

S4B32T722

A4

1

2

22X70

S7B32T722

A5

2

22X120

S5B32T1222

A4

1

1

22X120

S7B32T1222

1-11/32

A2

1

2

22X60

S4B34T622

A2

1

2

22X70

S4B34T722

A3

1

2

22X60

S5B34T622

A4

1

2

22X70

S7B34T722

1-3/8

A5

2

22X110

S5B35T1122

A4

1

2

20X120

S7Pb35T1220

1-7/16

A2

1

2

22X60

S4B36T622

A3

1

2

22X60

S5B36T622

A2

1

2

22X70

S4B36T722

A3

1

2

22X70

S5B36T722

1-1/2

A3

1

2

22X60

S5B38T622

A2

2

22X70

S4B38T722

A3

1

2

22X70

S5B38T722

A3

1

2

22X120

S5B38T1222

A4

1

2

22X110

S5B38T1122

1-9/16

A3

1

2

22X60

S5B40T622

A2

1

1

22X70

S5B40T722

A1

1

2

22X70

S5B40T722

A1

1

2

22X70

S5B40T723

1-5/8

A4

1

2

22X110

S7B41T1122

A4

1

2

20X120

S7B41T1220

1-21/32

A2

1

2

22X70

S4B42T722

A1

1

2

22X70

S5B42T723

1-3/4

A6

2

2

22X70

S6B45T722

A6

1

2

22X120

S6B45T1222
