Hard-facing Materials--->> YJ Alloyed Powder(Single-crystal WC Powder)

<<Back

1. Fully carbonized and dense alloyed powder

2. Carefully chosen material, special process to guarantee the preferable growth of grains

3. Compared with the conventiona tungsten carbide YJ has more uniforms structure, better thermal stability and coarser WC grains

4. Particle size:ranged from 20 microons to 5mm(American standard)

5. Single_crystal WC Powder is widely used as hard-surfacing material in diamond built-up welding on matrix and PCD drill pipe coating. It is a new kind of Tungsten Carbide material

Grade & Chemical Compositions

	Speciffic gravity (g/cm3)	Apparent density (g/cm3)	Chemical compositions(%)
	Speciffic gravity (g/cm3)	Apparent density (g/cm3)	T.C	F.C≤	Fe≤	Ti≤	Ta≤	Nb≤	Mo≤	Si≤
YJ	15.4～15.6	6.0～7.5	6.1～6.2	0.08	0.25	0.15	0.03	0.03	0.07	0.02
